ECHO BARRIER H9 1.2M X 2M
ECHO BARRIER H9 1.2M X 2M
The Echo Barrier H9™ delivers exceptional all-around performance, combining superior
noise absorption and attenuation with portability, durability, and versatility. Engineered
for resilience, it exhibits remarkable resistance to water and extreme temperatures,
effectively meeting the demands of various challenging environments, including high
humidity, freezing conditions, and exposure to heat sources.
The Echo Barrier H9™ delivers exceptional all-around performance, combining superior noise absorption and attenuation with portability, durability, and versatility. Engineered for resilience, it exhibits remarkable resistance to water and extreme temperatures, effectively meeting the demands of various challenging environments, including high humidity, freezing conditions, and exposure to heat sources.
The H9™ is rigorously tested to meet strict fire safety standards, including ASTM E84, EN, and BS fire resistance test standards, which confirm its low flame spread and smoke development properties. In summary, the Echo Barrier H9™ provides a comprehensive, high-performance noise control solution, perfectly suited for a wide range of applications and environments.
Product specification:
Max Noise Reduction (Lab Tested)*: 43 dB
Max Noise Absorption (Lab Tested)*: 100 %
Field results: Noise attenuation varies depending on site geometry
Height: 2050 mm (6 ft 9 in)
Width: 1335 mm (4 ft 5 in)
Rolled dimensions (optional): 400 mm (1 ft 4 in) diameter, 1335 mm (4 ft 5 in) wide
Weight: 5.5 kg (12 lb)
Fire resistant test standard*: BS 7837-1996, ASTM E84, EN 13501-1:2018
Water resistant test standard*: BSEN 60529:1992 IPX6 / IPX9
Dust resistant test standard*: BSEN 60529:1992 IP4X / IP5X
Cold resistant test standard*: BSEN 60068/2/1:2007
Tensile test standard*: ISO 17025 (5.85 kN or 1315 lbf vertical, 1.1 kN or 247 Ibf horizontal)
Light Fastness (UV resistance):
Yes - material components have various levels of protection as per their data sheets. PVC (front) has Light Fastness (UV resistance) greater than Grade 6 - EN ISO 105 B02. The membrane (back) has Light Fastness (UV resistance) of Grade 6 for all barriers manufactured after 2023 and Grade 4 for those manufactured before 2023.
Safety features: Two nighttime reflective strips, hazard icons
Quick install: 1 person in 30 seconds with installation kits, rollable (optional)
Installation kits: Yes (optional)
Buckle and clip (optional): Allows rolled barriers to be secured for easy handling
Anti-theft: Security cable, Data tag
Cleaning: Power wash
Identification code part number: Unique RFID number per each unit
Manufacturer’s warranty: 2 years
Colour options:Standard colours are green or blue (front) and black (back), other colour options are available on request.
